Underfloor Heating Projects

Electric heating mat under tiles build-up
Electric underfloor heating: two zones of 150W mats with Heatmiser neo
An electric underfloor heating system using 150W heating mats across two zones, both controlled from the Heatmiser neo app. Read more...
MaxHeatDeck cement-faced overlay board build-up
Loft conversion: low-profile cement-faced overlay underfloor heating
A loft conversion heated with 20mm cement-faced XPS overlay boards, keeping the floor build-up low where head height matters most. Read more...
Clip rail underfloor heating in screed
Northern Ireland: full loop design with flow rates, plus next-day supply
A full loop design for a project in Northern Ireland, with flow temperatures, flow rates and room outputs, then a grip rail in-screed system supplied next day. Read more...
Clip rail underfloor heating in screed
Edinburgh: pipe-in-screed for an installer, quoted in 3 hours, shipped the same day
A pipe-in-screed system supplied to an installer in Edinburgh: quoted within three hours, shipped the same day. Read more...
Underfloor heating pipe laid in a residential development
Manchester residential development: 12mm low-profile underfloor heating
Underfloor heating supply for a residential development in Manchester, using 12mm PEX-EVOH pipe in panels, fitted by one of our approved installers. Read more...
MaxHeatPro foil-faced panel build-up
London full ground floor: foil-faced XPS panels with MLCP pipe
A full ground floor in London on 20mm foil-faced XPS panels with 16mm MLCP pipe and wireless Heatmiser thermostats. Read more...
MaxHeatDeck cement-faced overlay board build-up
North London ground floor renovation: low-profile cement-faced overlay
A full ground floor renovation in North London using 20mm cement-faced XPS overlay boards to keep the floor build-up to a minimum. Read more...
UFH pipe clipped to insulation ready for screed
London full property renovation: 240m² of underfloor heating for a heat pump
240m² across three floors of a London renovation: in-screed downstairs, overlay upstairs, all at 150mm centres for an air source heat pump. Read more...
MaxHeatChip grooved chipboard underfloor heating
Whole-house, multi-zone underfloor heating under LVT with Heatmiser neo
A whole-house, multi-zone system under LVT flooring, using MaxHeatChip and MaxHeatDeck, all controlled from one Heatmiser neo app. Read more...
MaxHeatDeck cement-faced overlay board build-up
Gawsworth, Cheshire: loop design for a three-storey house
A full loop design for a three-storey house in Gawsworth: pipe clipped to insulation on the ground floor, overlay boards on the first and second floors. Read more...
MaxHeatDeck cement-faced overlay board build-up
Cheshire East: full three-floor heating replacement with Heatmiser control
A complete heating replacement across the ground, first and second floors of a Cheshire East home, with Heatmiser thermostats in every zone. Read more...
UFH pipe clipped to insulation in a new build
Cheshire East new build development: four homes, one UFH spec
Underfloor heating supply for a four-property new build development in Cheshire East, phased one home at a time. Read more...
UFH pipe clipped to insulation ready for screed
Northwich, Cheshire: ground floor pipe-in-screed
A ground floor pipe-in-screed system near Northwich, with 16mm PERT-AL-PERT pipe clipped straight to the insulation. Read more...
Foil-faced overlay board with UFH pipe
Warrington, Cheshire: screed downstairs, low-profile overlay upstairs
Two floor constructions in one Warrington home: pipe-in-screed on the ground floor and 20mm foil-faced overlay boards upstairs. Read more...
Pipe clipped to insulation ready for screed
Cheshire barn conversion: in-screed underfloor heating for an air source heat pump
A farm barn conversion in Cheshire with pipe-in-screed underfloor heating at 150mm centres, designed around an air source heat pump. Read more...
MaxHeatChip grooved chipboard underfloor heating over timber joists
Lake District: chipboard underfloor heating with room-by-room app control
A timber-floored home in the Lake District, heated with a 22mm grooved chipboard system, cement cover boards and Heatmiser app control in every room. Read more...
