UFH Manifold Blending Valve Pump Pack 20–55°C with Bastion A-Rated 6m Pump
Product details
This UFH manifold blending valve pump pack comes with a Bastion A-rated 6m-head circulator. It suits standard-sized underfloor heating systems on one manifold. The thermostatic valve blends primary flow with return water to give a steady 20–55°C to the floor, and the pack arrives pre-assembled with the pump's power cable.
Why installers use it
- Bastion 6m pump: A-rated and high efficiency, with the power cable in the box.
- PWM option: add the Bastion PWM signal cable if you want speed control.
- Works with boilers and heat pumps: the 20–55°C range covers both.
- Ready to bolt on: pre-assembled and tested.
Specification
| Item | Detail |
|---|---|
| Mixed flow temperature | 20–55°C, adjustable |
| Valve | Thermostatic wax capsule, no wiring |
| Mounting | Manifold flow and return bars |
| Max system pressure | 10 bar |
| Pump | Bastion A-rated, 6m head, cable included |
Works with
- Dualmix Stainless Steel Manifold Assembly
- 3/4" Ball Valve Set for Blending Valve
- Bastion Replacement Pump Cables
- Blending Valve Pump Pack with Bastion 7.5m Pump for bigger systems
Questions
Does the blending valve need wiring?
No. It's a thermostatic wax-capsule valve, so only the pump needs power.
6m or 7.5m?
The 6m suits most single-manifold jobs. Go for the 7.5m version if the system is large or the loops are long.
Order by 12pm, Monday to Friday, for next working day UK delivery.
Product codes: MH-BV55-BAS6
Specifications
| Brand | Bastion |
|---|---|
| Code | MH-BV55-BAS6 |
| Type | Pump & Controls |
