UFH Manifold Blending Valve Pump Pack 20–55°C with Bastion A-Rated 7.5m Pump
Product details
This UFH manifold blending valve pump pack uses the higher-head Bastion A-rated 7.5m circulator. Choose it for larger systems or longer loops, where a 6m pump may struggle. The thermostatic valve holds a steady 20–55°C to the floor, and the pack arrives pre-assembled with the pump's power cable.
Why installers use it
- 7.5m head: extra head for big floor areas and long loops.
- Cable supplied: the Bastion power cable comes with it.
- Thermostatic mixing: a wax-capsule valve with no wiring needed.
- Manifold mounted: bolts to the flow and return bars.
Specification
| Item | Detail |
|---|---|
| Mixed flow temperature | 20–55°C, adjustable |
| Valve | Thermostatic wax capsule, no wiring |
| Mounting | Manifold flow and return bars |
| Max system pressure | 10 bar |
| Pump | Bastion A-rated, 7.5m head, cable included |
Works with
- Auto-Balancing Stainless Steel UFH Manifold
- 3/4" Ball Valve Set for Blending Valve
- Pressure / Temperature Gauge for UFH Mixing Unit
- Bastion Replacement Pump Cables
Questions
When do I need the 7.5m pump?
On larger systems or longer loops. If you're not sure, send us your plans and we'll check.
Can I use it with a heat pump?
Yes. The 20–55°C range goes low enough for heat pumps and low-temperature floors, as well as boiler-fed systems.
Order by 12pm, Monday to Friday, for next working day UK delivery.
Product codes: MH-BV55-BAS75
Specifications
| Brand | Bastion |
|---|---|
| Code | MH-BV55-BAS75 |
| Type | Pump & Controls |
