3/4" Ball Valve Set for Blending Valve (Red & Blue, Pair)
Product details
A pair of 3/4" full-bore isolating ball valves for the primary connections of an underfloor heating blending valve or pump pack. Close them to isolate the UFH unit from the boiler or heat pump for servicing, without draining the system.
Why installers use it
- Service without draining: isolate the pump pack in seconds.
- Red and blue handles: flow and return are easy to tell apart.
- Full bore: no restriction when open.
- Robust: nickel-plated brass with PTFE seats, rated to 10 bar and 110°C.
Specification
| Item | Detail |
|---|---|
| Size | 3/4" BSP |
| Handles | 1 red, 1 blue |
| Material | Nickel-plated brass, PTFE seats |
| Rating | 10 bar, 110°C |
Works with
- Blending valve pump pack with Grundfos UPM3 Auto
- Blending valve, valve only
- Manifold Ball Valve Set 1"
- All ball valves
Questions
Is it a pair?
Yes. One red valve and one blue valve.
Where do they go?
On the primary flow and return into the blending valve or pump pack, between it and the boiler or heat pump.
