Copper M-Press Male Elbow
Product details
A copper M-press male elbow presses onto copper tube at one end and has a male thread at the other, with a 90° turn between. Screw it into a female port on a valve, cylinder, manifold or appliance and take the tube away at a right angle. Sizes are 15mm x 1/2", 22mm x 3/4" and 28mm x 1".
Why installers use it
- Straight into a port: the male thread screws into a female connection.
- Saves a fitting: turn and adapt in one, instead of an adaptor plus elbow.
- Press the tube end: flame-free, so safe close to plastic parts and controls.
- Full packs: bag or box. Packs are not split.
Pack sizes
| Size | Bag | Box |
|---|---|---|
| 15mm x 1/2" | 10 | 120 |
| 22mm x 3/4" | 5 | 60 |
| 28mm x 1" | 5 | 40 |
Works with
- Copper M-Press Female Elbow
- Copper M-Press Male Straight
- MaxHeatUFH M-Profile Press Jaws in 15, 22 and 28mm
- Copper M-Press Fittings
Questions
Male or female elbow?
Choose male to screw into a female port. Choose the female elbow when the part you are connecting has a male thread.
Can I buy single fittings?
No. Our supplier does not split packs, so we sell full bags and boxes only.
Order by 12pm, Monday to Friday, for next working day UK delivery.
Product codes: MHF9-L15x1/2M, MHF9-L22x3/4M, MHF9-L28x1M
Specifications
| Brand | MaxHeatUFH |
|---|---|
| Code | MHF9-L15x1/2M-BAG10 |
| Type | Copper M-Press Fitting |
| Size | 15mm x 1/2", 22mm x 3/4", 28mm x 1" |
| Pack | Bag, Box |
Delivery & returns
Next working day delivery on UK mainland orders placed by 12pm, Monday to Friday. Delivery is calculated at checkout. See our delivery and shipping policy and returns policy.
Need help choosing?
Try our MaxHeatUFH ProLoop to design and price your floor, or email sales@maxheatufh.com with your floor plan.
