Full Bore Lever Ball Valve, Compression, WRAS Approved
Product details
A WRAS approved full bore lever ball valve with compression ends, for isolating hot and cold water and heating pipework. The full bore design gives maximum flow with minimal pressure drop. It suits jobs where you want a valve that can be fitted with spanners rather than a press tool.
Why installers use it
- Full bore: maximum flow with minimal pressure drop.
- Quarter-turn lever: fully open or fully shut in a quarter turn.
- Compression ends: compression x compression, fitted with spanners.
- Sold singly: buy exactly the number you need.
Specification
| Detail | Value |
|---|---|
| Sizes | 15, 22, 28, 35mm |
| Ends | Compression x compression |
| Body | Brass |
| Ball | Chrome-plated |
| Seats | PTFE |
| Approval | WRAS approved |
Works with
Questions
Do I need a press tool?
No. This valve has compression ends. If you are pressing the rest of the job, see our M-press lever ball valve.
Is it sold in packs?
No. Each valve is sold on its own.
Order by 12pm, Monday to Friday, for next working day UK delivery.
Product codes: MH-LBV-15, MH-LBV-22, MH-LBV-28, MH-LBV-35
Specifications
| Brand | MaxHeatUFH |
|---|---|
| Code | MH-LBV-15 |
| Type | Plumbing & Heating Valve |
| Size | 15mm, 22mm, 28mm, 35mm |
Delivery & returns
Next working day delivery on UK mainland orders placed by 12pm, Monday to Friday. Delivery is calculated at checkout. See our delivery and shipping policy and returns policy.
Need help choosing?
Try our MaxHeatUFH ProLoop to design and price your floor, or email sales@maxheatufh.com with your floor plan.
