Copper M-Press Lever Ball Valve
Product details
A copper M-press lever ball valve isolates a copper run, with press ends on both sides so it goes straight onto the tube. Choose a red or blue handle so hot and cold, or flow and return, are easy to tell apart. Sizes are 15mm, 22mm, 28mm and 35mm.
Why installers use it
- Press both ends: no compression nuts or solder.
- Colour coded: red or blue lever handle on every size.
- Lever action: on or off with a turn of the handle.
- Full packs: bags of 2 in 15mm and 22mm. 28mm and 35mm come by the box.
Pack sizes (each colour)
| Size | Bag | Box |
|---|---|---|
| 15mm x 15mm | 2 | 54 |
| 22mm x 22mm | 2 | 36 |
| 28mm x 28mm | – | 24 |
| 35mm x 35mm | – | 18 |
Works with
- Lever Ball Valve with Female Connection
- Full Bore Lever Ball Valve, Compression
- Ball Valves and Valves
Questions
Can I mix red and blue in one bag?
No. Each pack is one handle colour and one size. Our supplier does not split packs.
Which press tool do I need?
Any tool that takes M-profile jaws in the size you are pressing. With MaxHeatUFH jaws, 15, 22 and 28mm fit both the Electric Hydraulic Press Tool (MH-EHCS) and the High Power tool (MH-HPEHCS). 35, 42 and 54mm need the High Power tool.
Order by 12pm, Monday to Friday, for next working day UK delivery.
Product codes: MHF9-LBV15x15B/R to MHF9-LBV35x35B/R
Specifications
| Brand | MaxHeatUFH |
|---|---|
| Code | MHF9-LBV15x15R-BAG2 |
| Type | Copper M-Press Fitting |
| Size | 15mm x 15mm, 22mm x 22mm, 28mm x 28mm, 35mm x 35mm |
| Handle colour | Red, Blue |
| Pack | Bag, Box |
Delivery & returns
Next working day delivery on UK mainland orders placed by 12pm, Monday to Friday. Delivery is calculated at checkout. See our delivery and shipping policy and returns policy.
Need help choosing?
Try our MaxHeatUFH ProLoop to design and price your floor, or email sales@maxheatufh.com with your floor plan.
