Single Room UFH Mixing Pump Pack with Wilo A-Rated 6m Pump
Product details
A single room underfloor heating mixing pump pack with a Wilo A-rated 6m-head pump and its power cable. It lets you add wet UFH to one room, such as an extension, kitchen or conservatory, straight off a radiator or boiler circuit. A thermostatic mixing valve holds a steady 35–60°C to the floor loop, and the pack comes with primary isolation valves and a pre-wired pump terminal box.
Why installers use it
- Wilo 6m pump: A-rated, high-efficiency, cable supplied.
- 35–60°C mixed flow: a thermostatic valve protects the floor from boiler temperatures.
- No manifold: one circuit for one room.
- Pre-assembled and tested: ready to install.
Specification
| Item | Detail |
|---|---|
| Mixing valve | Thermostatic |
| Mixed flow temperature | 35–60°C |
| Circuits | 1 (single room) |
| Fitted | Primary isolation valves, pre-wired terminal box |
| Max system pressure | 10 bar |
| Pump | Wilo A-rated, 6m head, cable included |
Works with
- PERT-AL-PERT Multilayer UFH Pipe
- Heatmiser DS1 Thermostat
- Wilo Replacement Pump Power Cable
- ESBE version with Wilo 6m pump
Questions
Standard or ESBE pack?
Both run one room at 35–60°C. The ESBE pack adds an ESBE valve with built-in bypass and its own wall back plate.
Is the pump wired?
The pump terminal box is pre-wired and the Wilo power cable is included.
Order by 12pm, Monday to Friday, for next working day UK delivery.
Product codes: MH-SR-WILO6
