ESBE Single Room UFH Mixing Pump Pack with Wilo A-Rated 6m Pump
Product details
This ESBE single room UFH mixing pump pack is fitted with a Wilo A-rated 6m-head pump, supplied with its power cable. It's a straightforward way to heat one room, such as an extension, kitchen or conservatory, from an existing radiator or boiler circuit. The ESBE valve has a built-in bypass and holds a steady 35–60°C to the floor loop, and the pack mounts on its own wall back plate.
Why installers use it
- Wilo 6m pump: A-rated, high efficiency, cable included.
- ESBE thermostatic valve: built-in bypass, 35–60°C mixed flow.
- Single circuit: no manifold to buy or fit.
- Pre-assembled and tested: on a wall back plate with primary isolation valves.
Specification
| Item | Detail |
|---|---|
| Mixing valve | ESBE thermostatic, built-in bypass |
| Mixed flow temperature | 35–60°C |
| Circuits | 1 (single room) |
| Mounting | Own wall back plate |
| Max system pressure | 10 bar |
| Pump | Wilo A-rated, 6m head, cable included |
Works with
- PERT-AL-PERT Multilayer UFH Pipe
- Heatmiser DS1 Thermostat
- Wilo Replacement Pump Power Cable
- Pressure / Temperature Gauge for UFH Mixing Unit
Questions
Can I add it to a radiator system?
Yes. It's designed to run one UFH circuit straight off an existing radiator or boiler circuit.
What pressure is it rated to?
Up to 10 bar system pressure.
Order by 12pm, Monday to Friday, for next working day UK delivery.
Product codes: MH-SRE-WILO6
