ESBE Single Room UFH Mixing Pump Pack with Grundfos UPM3 Auto
Product details
This ESBE single room UFH mixing pump pack is fitted with a Grundfos UPM3 Auto 25-70 130, which uses AUTOADAPT to set itself to the circuit. It suits a one-room job where you want the pump to look after itself. Use it for an extension, kitchen or conservatory run off a radiator or boiler circuit. The ESBE valve has a built-in bypass and holds a steady 35–60°C to the floor loop, and the pack mounts on its own wall back plate.
Why installers use it
- Self-setting pump: AUTOADAPT, plus proportional pressure, constant pressure and constant curve.
- Up to 7m head: from the UPM3 Auto 25-70.
- ESBE bypass valve: keeps a steady 35–60°C to the floor.
- Wall mounted: on its own back plate, with isolation valves fitted.
Specification
| Item | Detail |
|---|---|
| Mixing valve | ESBE thermostatic, built-in bypass |
| Mixed flow temperature | 35–60°C |
| Circuits | 1 (single room) |
| Mounting | Own wall back plate |
| Max system pressure | 10 bar |
| Pump | Grundfos UPM3 Auto 25-70 130, up to 7m head |
Works with
- UFH pipe
- Heatmiser DS1 Thermostat
- ESBE Single Room Pack with Grundfos UPM3 Flex if you need PWM control
- Grundfos Replacement Pump Power Cable (UPM3)
Questions
Is the pump wired?
The pump terminal box is pre-wired on the pack, so you only need to bring the supply to it.
Which rooms does it suit?
Any single room with one UFH circuit, such as an extension, kitchen or conservatory.
Order by 12pm, Monday to Friday, for next working day UK delivery.
Product codes: MH-SRE-UPM3A
