Single Room UFH Mixing Pump Pack with Bastion A-Rated 6m Pump
Product details
A single room UFH mixing pump pack fitted with a Bastion A-rated 6m-head pump and its power cable. It's a simple way to heat one standard room, such as a kitchen or small extension, from an existing radiator or boiler circuit. A thermostatic mixing valve holds a steady 35–60°C to the floor loop, and the pack comes with primary isolation valves and a pre-wired pump terminal box.
Why installers use it
- Bastion 6m pump: A-rated, with power cable supplied.
- Thermostatic mixing: 35–60°C to the floor loop.
- PWM option: add the Bastion PWM signal cable if you want speed control.
- Ready to install: pre-assembled and tested.
Specification
| Item | Detail |
|---|---|
| Mixing valve | Thermostatic |
| Mixed flow temperature | 35–60°C |
| Circuits | 1 (single room) |
| Fitted | Primary isolation valves, pre-wired terminal box |
| Max system pressure | 10 bar |
| Pump | Bastion A-rated, 6m head, cable included |
Works with
- UFH pipe
- Heatmiser DS1 Thermostat
- Bastion Replacement Pump Cables
- Single Room Pack with Bastion 7.5m Pump for longer loops
Questions
Do I need a manifold?
No. It runs one UFH circuit straight off the radiator or boiler circuit.
What pressure is it rated to?
Up to 10 bar system pressure.
Order by 12pm, Monday to Friday, for next working day UK delivery.
Product codes: MH-SR-BAS6
Specifications
| Brand | Bastion |
|---|---|
| Code | MH-SR-BAS6 |
| Type | Pump & Controls |
Delivery & returns
Next working day delivery on UK mainland orders placed by 12pm, Monday to Friday. Delivery is calculated at checkout. See our delivery and shipping policy and returns policy.
Need help choosing?
Try our MaxHeatUFH ProLoop to design and price your floor, or email sales@maxheatufh.com with your floor plan.
