Copper M-Press Equal Straight Coupling
Product details
A copper M-press straight coupling joins two lengths of the same size copper tube in a straight line. It is one of our best-selling copper press fittings, used on heating and water runs from 15mm to 54mm. You press it with an M-profile jaw, so there is no flame and no solder on site.
Why installers use it
- Flame-free joints: press each end with an M-profile press tool and the matching jaw.
- Six sizes: 15, 22, 28, 35, 42 and 54mm, all equal both ends.
- Packs for every job: a bag for the van or a box for bigger runs. Our supplier does not split packs.
Pack sizes
| Size | Bag | Box |
|---|---|---|
| 15mm | 10 | 180 |
| 22mm | 10 | 90 |
| 28mm | 10 | 60 |
| 35mm | 5 | 25 |
| 42mm | 2 | 20 |
| 54mm | 2 | 12 |
Works with
- MaxHeatUFH M-Profile Press Jaws and the Electric Hydraulic Press Tool Set
- Copper M-Press Equal Sleeve Coupling
- Copper M-Press Straight Reducer
- Copper M-Press Fittings
Questions
Which press tool do I need?
Any tool that takes M-profile jaws in the size you are pressing. With MaxHeatUFH jaws, 15, 22 and 28mm fit both the Electric Hydraulic Press Tool (MH-EHCS) and the High Power tool (MH-HPEHCS). 35, 42 and 54mm need the High Power tool.
Can I buy single fittings?
No. Our supplier does not split packs, so we sell full bags and boxes only.
Order by 12pm, Monday to Friday, for next working day UK delivery.
Product codes: MHF9-SC15x15, MHF9-SC22x22, MHF9-SC28x28, MHF9-SC35x35, MHF9-SC42x42, MHF9-SC54x54
Specifications
| Brand | MaxHeatUFH |
|---|---|
| Code | MHF9-SC15x15-BAG10 |
| Type | Copper M-Press Fitting |
| Size | 15mm, 22mm, 28mm, 35mm, 42mm, 54mm |
| Pack | Bag, Box |
