3-Port Mid-Position Motorised Valve 22mm
Product details
A 22mm 3-port mid-position motorised valve for Y-plan heating and hot water control. One valve gives you heating only, hot water only, or both at once. It has a removable 230V actuator head and 22mm compression connections.
Why installers use it
- Three modes from one valve: heating, hot water, or both.
- Removable actuator head: easier to wire, and the head can be swapped without draining down.
- 22mm compression: no soldering or pressing needed to fit.
- 230V: wires to a standard 230V programmer and thermostats.
Specification
| Item | Detail |
|---|---|
| Size | 22mm compression |
| Type | 3-port mid-position (Y-plan) |
| Voltage | 230V |
| Actuator | Removable head |
Wiring should be done by a qualified electrician.
Works with
- 2-Port Motorised Zone Valve for S-plan zoning
- Valves
- Pumps, actuators and valves
Questions
Is this for Y-plan or S-plan?
Y-plan. In an S-plan system you use a 2-port valve for each zone instead.
Can I change just the head?
Yes. The actuator head is removable, so it can be replaced on its own.
Order by 12pm, Monday to Friday, for next working day UK delivery.
Product codes: MH-ZV3-22
Specifications
| Brand | MaxHeatUFH |
|---|---|
| Code | MH-ZV3-22 |
| Type | Pump & Controls |
