Copper M-Press Full Crossover
Product details
A copper M-press full crossover lets one pipe hop over another where two runs cross, without making up an offset from elbows. It is pressed at both ends with M-profile jaws and comes in 15mm and 22mm, the sizes most used for heating and water distribution in homes.
Why installers use it
- One fitting, not four: replaces a made-up offset of elbows or bends.
- Neat crossings: keeps runs flat in floor voids and boxing.
- 15mm and 22mm: equal at both ends, pressed with standard M-profile jaws.
- Full packs: bag or box only. Our supplier does not split packs.
Pack sizes
| Size | Bag | Box |
|---|---|---|
| 15-15mm | 10 | 40 |
| 22-22mm | 5 | 20 |
Works with
- Copper M-Press Partial Crossover
- MaxHeatUFH M-Profile Press Jaws in 15 and 22mm, which fit the Electric Hydraulic Press Tool Set
- Copper M-Press Fittings
Questions
Full or partial crossover?
We sell both in the same sizes. Pick the shape that suits the space you have, or ask us if you are unsure.
Which press tool do I need?
Any tool with 15mm or 22mm M-profile jaws. Our MH-EHCS and MH-HPEHCS tools both take these sizes.
Order by 12pm, Monday to Friday, for next working day UK delivery.
Product codes: MHF9-FC15x15, MHF9-FC22x22
Specifications
| Brand | MaxHeatUFH |
|---|---|
| Code | MHF9-FC15x15-BAG10 |
| Type | Copper M-Press Fitting |
| Size | 15-15mm, 22-22mm |
| Pack | Bag, Box |
Delivery & returns
Next working day delivery on UK mainland orders placed by 12pm, Monday to Friday. Delivery is calculated at checkout. See our delivery and shipping policy and returns policy.
Need help choosing?
Try our MaxHeatUFH ProLoop to design and price your floor, or email sales@maxheatufh.com with your floor plan.
